GI Pipes & Application

Galvanized Steel are those steel that has been covered with a layer of zinc metal. During galvanizing, steel is immersed in a molten zinc bath, ensuring a tough, uniform barrier coating. Zinc's natural corrosion resistance provides long-term protection, even in outdoor environments. Apart from preventing water corrosion, it is equally effective in dry, indoor environments. GI pipes and tubes are mostly used in structural applications. GI steel pipes and tubes are available in various size and shapes based on the customer requirements.

Product Range

Product Range	GI Pipes
OD	½" to 14" (NB - 15 MM to 350 MM)
Thickness	2.00 MM to 9.50 MM
Specification	IS: 1239/3589 Fe-330/410/ IS: 1161/4270, YST. -210/240/310

SIZE	NB - (Nominal Bore)	OD (MM) -Outer Dia	CLASS	Thk. (MM)
½"	15 MM	21.3	LIGHT	2
			MEDIUM	2.6
			HEAVY	3.2
¾"	20 MM	26.7	LIGHT	2.30
			MEDIUM	2.6
			HEAVY	3.2
1"	25 MM	33.4	LIGHT	2.60
			MEDIUM	3.2
			HEAVY	4
1¼"	32 MM	42.2	LIGHT	2.6
			MEDIUM	3.2
			HEAVY	4
1½"	40 MM	48.3	LIGHT	2.90
			MEDIUM	3.2
			HEAVY	4
2""	50 MM	60.3	LIGHT	2.90
			MEDIUM	3.6
			HEAVY	4.5
2½"	65 MM	76.1/73	LIGHT	3.20
			MEDIUM	3.6
			HEAVY	4.5
3"	80 MM	88.9	LIGHT	3.20
			MEDIUM	4
			HEAVY	4.8
4"	100 MM	114.3	LIGHT	3.60
			MEDIUM	4.5
			HEAVY	5.4
5"	125 MM	139.7	MEDIUM	4.8
			HEAVY	5.4
6"	150 MM	165.1	MEDIUM	4.8
			HEAVY	5.4

SIZE	NB - (Nominal Bore)	OD (MM) -Outer Dia	Thk. (MM)
8"	200 MM	219.1	5
			6
			6.35
			7
			8
			9.5
10"	250 MM	273	5
			6
			6.35
			7
			8
			9.5
12"	300 MM	323.9	5
			6
			6.35
			7
			8
			9.5
14"	350 MM	355.6	5
			6
			6.35
			7
			8
			9.5
16"	400 MM	406.4	5
			6
			6.35
			7
			8
			9.5
18"	450 MM	457.2	5
			6
			6.35
			7
			8
			9.5
20"	500 MM	508	5
			6
			6.35
			7
			8
			9.5
